September 2001 88XX Series Folder Operator Manual 16
Switching on the Folder
At power on, the Firmware release will be displayed for two seconds:
− as a code in the Numeric Control Panel [RX.XX ]
− as a message in the Alphanumeric Control Panel “REV. X.XX“
When 2 - 3 seconds has expired, the control panels will show either
“idle”, an alarm status or (if the system has already submitted a job), the
program selected.
− as a code in the Numeric Control Panel [ le], [A-XX] or [P-XX].
− as a message in the Alphanumeric Control Panel “IDLE”,
“190+20” or “DOOR OPEN”
During the folding process, error messages will be displayed:
− as a code in the Numeric Control Panel [E-XX]
− as a message in the Alphanumeric Control Panel
Code Message Code Message
a-
01
DOOR OPEN a-07 ENCODER OR M2 MOTOR FAULT
a-
02
BRIDGE SENSORS
COVERED
a-08 STEP MOTORS FAULT
a-
03
UPPER POCKET
SENSOR COVERED
a-09 NOT IMPLEMENTED
a-
04
LOWER POCKET
SENSOR COVERED
a-10 NOT IMPLEMENTED
a-
05
CROSS POCKETS
SENSOR COVERED
a-11 FIRST BIN FULL
a-
06
24V MISSING a-12 SECOND BIN FULL
Other errors
Code Description
S
Not settable value. Folder could generate unexpected
folding styles due to particular value situation.
Is not possible to adjust the style
Code Message Code Message
p-00 NO FOLD P-10 CUSTOM
p-01 185 p-11 7,5”
p-02 185+25 p-12 7,5”+1”
p-03 190 P-13 8,5”
p-04 190+20 P-14 9”
p-05 198 p-15 WALLET 11”
p-06 210 p-16 WALLET 12”
p-07 AFNOR p-17 7,5” LANDSCAPE
p-08 ERICSSON p-18 8,5” LANDSCAPE
p-09 FRENCH p-19 9” LANDSCAPE
Code Message
e-01 ENTRY ALARM 1
e-02 ENTRY ALARM 2
e-03 BRIDGE ALARM
e-04 ROTATION ALARM
e.-05 POCKETS ALARM
e-06 FOLDING ALARM 1
e-07 FOLDING ALARM 2
e-08 FOLDING ALARM 3
e-09 FAN FOLDER EXIT ALARM
e-10 TRANSPORT ALARM
e-11 CROSS ENTRY ALARM
e-12
CROSS EXIT ALARM
CROSS EXIT ALARM W/PUNCHING
e-13 NOT FOLDABLE
E-14 NOT AVAILABLE SELECTION
E-15 LAPS WITHOUT ADJUSTMENT
E-16
E-17 PROGRAM NOT SELECTABLE
Note : l SENSOR COVERED ¡ SENSOR UNCOVERED
