Xerox 8830 Operator's Manual

September 2001 88XX Series Folder Operator Manual 25
Manual Feed Procedure
The following Manual Feed Mode sequence describes the detailed steps
to be used, and where to find supporting information:
1. Refer to Fan Programs Submenu and Cross Programs Submenu to
select the folded output package style and to return to complete the
set up process*.
2. Choose optional finishing features, holes and bin usage. Go to
Punching Submenu and Stacker Submenu*.
3. Enter the Manual Feed Procedure submenu to set the location of the
title block and the size of the document*.
Enter the “TITLE BLOCK LOCATION” submenu [ U6.01 ].
Select the corner in which you will locate the title block.
− LOCATION 1 [ 01 ]
− LOCATION 2 [ 02 ]
− LOCATION 3 [ 03 ]
− LOCATION 4 [ 04 ]
Input the Document size in one of the two method below:
A. If the document conforms to one of the listed multinational
configurations, simply select a Standard size as follows:
Go to the “STANDARD” submenu [ U6.02 ] and press “Enter”
to access to the three submenus.
− ISO [ ISO ]
− ANSI [ ansi ]
− ARCH [ arch ]
* The folder shows as default the last selection made by the operator.
Select the desired standard and press “Enter.”
− Select ISO sizes: A3, A2, A1, A0
− Select ANSI sizes: B, C, D, E
− Select ARCH sizes: B, C, D, E
B. If the document does not conform to one of any multinational
configurations listed before, provide the length information as
follows.
Go to the “ROLL” submenu [ U6.03 ], press “Enter” to access
to the list of available rolls. Scroll until the desired roll size
appears and press “Enter” to set it.
The folder accepts rolls between 280mm and 914mm, which are
chosen from the ones listed in the table below.
Alphanumeric
Control Panel
Numeric
Control Panel
Description
11” 11 ‘
280mm 11inches
297 297
297mm
12” 12 ‘
305mm 12inches
420 420
420mm
17” 17 ‘
432mm 17inches
18” 18 ‘
457mm
22” 22 ’
559mm 22inches
594 594
594mm
24” 24 ‘
610mm 24inches
620 620
620mm
30” 30 ‘
762mm 30inches
841 841
841mm
34” 34 ‘
864mm 34inches
900 900
900mm
36” 36 ‘
914mm
1
2
4
3
