September 2001 88XX Series Folder Operator Manual 41
Clearing Bridge Jams
When the folder emits a single alarm tone and stops, there is probably a
strip of media stuck on the bridge.
112619
To clear the jam:
1. Open the bridge door (A).
2. Insert the safety lever (B).
3. Remove the media.
4. Close the bridge door.
5. Press Reset.
Clearing Fan Folder Jams
Manual Eject Procedure
When the folder emits a double tone, there is a jam located in the Fan
Folder. The folder will try to clear the jammed print automatically. If the
print is not cleared, perform the following steps.
1. Press and hold the “Reset” key for more than two seconds. The
rollers will then rotate, and the Control Display will show the
message “MANUAL EJECT - PLEASE SURVEY THE
FOLDER”
2. Release the Reset key to stop the rollers, (Press the “Reset” key to
restart the rollers.)
− The jammed print should exit the folder.
3. When the jam has been cleared, wait five seconds and press the
“Reset” key for less than two seconds to return the folder to normal
operating conditions.
NOTE. If the print is not cleared, proceed with Clearing Upper and
Lower Pocket Jams or Clearing Mobile Roller Jams.
A
B
