September 2001 88XX Series Folder Operator Manual 23
Manual Feed Submenu
Use this submenu to set the size and the title block location of the print
that has to be manually fed.
1. Go to the “Manual Feed” submenu.
in the Numeric Control Panel in the Alphanumeric Control Panel
u OPERATOR
U6 MANUAL FEED
2. Enter the last level of the menu to set:
− “TITLE BLOCK LOCATION” [ u6.01 ]
Set the title block location. Press ”Enter” to access the following
options:
− LOCATION 1 [ 01 ]
− LOCATION 2 [ 02 ]
− LOCATION 3 [ 03 ]
− LOCATION 4 [ 04 ]
− “STANDARD” [ U6.02 ]
Use this selection for standard sizes.
− “ROLL” [ U6.03 ]
Use this menu to set the roll width if the size is not standard.
− “LENGTH” [ U6.04 ]
If the size is not standard, it is possible
to set the length in this submenu.
− “AUTOLENGTH” [ U6.05 ]
Automatic length detection, future
option.
− Select FEED IN [ u6.06 ] to activate
the entry flap and to set the folder ready
to be Manual Feed.
− Select EXIT [ u6.00 ] to rise one level.
For a complete description of the
“Manual Feed” procedure, refer to the
next pages: “Manual Feed Procedure”
Manual
feed
u 6
A
uto
length
u 6.05
Feed in
u 6.06
Roll
u 6.03
Length
u 6.04
Title block
location
u 6.01
u 6.02
Standard
sizes
Exit
u 6.00
