Chapter 1: ML605 Evaluation Board
Table 1-8 shows the PCIe connector (P1) that provides up to 8-lane access through the GTX
transceivers to the Virtex-6 FPGA Integrated Endpoint block for PCIe designs.
Table 1-8: PCIe Edge Connector Connections
U1 FPGA
Pin
Schematic Net Name
P1 PCIe Edge Connector
Description
Package
Placement
Pin Number Pin Name
F1 PCIE_TXO_P A16 PERp0
Integrated Endpoint block
transmit pair
GTXE1_X0Y15
F2 PCIE_TXO_N A17 PERn0
H1 PCIE_TX1_P A21 PERp1
Integrated Endpoint block
transmit pair
GTXE1_X0Y14
H2 PCIE_TX1_N A22 PERn1
K1 PCIE_TX2_P A25 PERp2
Integrated Endpoint block
transmit pair
GTXE1_X0Y13
K2 PCIE_TX2_N A26 PERn2
M1 PCIE_TX3_P A29 PERp3
Integrated Endpoint block
transmit pair
GTXE1_X0Y12
M2 PCIE_TX3_N A30 PERn3
P1 PCIE_TX4_P A35 PERp4
Integrated Endpoint block
transmit pair
GTXE1_X0Y11
P2 PCIE_TX4_N A36 PERn4
T1 PCIE_TX5_P A39 PERp5
Integrated Endpoint block
transmit pair
GTXE1_X0Y10
T2 PCIE_TX5_N A40 PERn5
V1 PCIE_TX6_P A43 PERp6
Integrated Endpoint block
transmit pair
GTXE1_X0Y9
V2 PCIE_TX6_N A44 PERn6
Y1 PCIE_TX7_P A47 PERp7
Integrated Endpoint block
transmit pair
GTXE1_X0Y8
Y2 PCIE_TX7_N A48 PERn7
J3 PCIE_RXO_P B14 PETp0
Integrated Endpoint block
receive pair
GTXE1_X0Y15
J4 PCIE_RXO_N B15 PETn0
K5 PCIE_RX1_P B19 PETp1
Integrated Endpoint block
receive pair
GTXE1_X0Y14
K6 PCIE_RX1_N B20 PETn1
L3 PCIE_RX2_P B23 PETp2
Integrated Endpoint block
receive pair
GTXE1_X0Y13
L4 PCIE_RX2_N B24 PETn2
N3 PCIE_RX3_P B27 PETp3
Integrated Endpoint block
receive pair
GTXE1_X0Y12
N4 PCIE_RX3_N B28 PETn3
R3 PCIE_RX4_P B33 PETp4
Integrated Endpoint block
receive pair
GTXE1_X0Y11
R4 PCIE_RX4_N B34 PETn4
U3 PCIE_RX5_P B37 PETp5
Integrated Endpoint block
receive pair
GTXE1_X0Y10
U4 PCIE_RX5_N B38 PETn5
W3 PCIE_RX6_P B41 PETp6
Integrated Endpoint block
receive pair
GTXE1_X0Y9
W4 PCIE_RX6_N B42 PETn6
