Xilinx SP605 User Manual

14 www.xilinx.com SP605 Hardware User Guide
UG526 (v1.9) February 14, 2019
Chapter 1: SP605 Evaluation Board
7
Clock Generation
200 MHz OSC, oscillator socket,
SMA connectors
13, 14
a. 200 MHz oscillator SiTime 200 MHz 2.5V LVDS 14
b. Oscillator socket, single-
ended, LVCMOS
MMD Components 2.5V 27 MHz 14
c. SMA connectors SMA pair P(J41) / N(J38) 13
8
GTP port SMA x4 and
MGT Clocking SMA (REFCLK)
MGT RX,TX Pairs x4 SMA MGT
REFCLK x2 SMA
13
9 PCIe 1-lane edge conn.(Gen 1) Card Edge Connector, 1-lane 12
10 SFP Module Cage/Connector AMP 136073-1 12
11 Ethernet 10/100/1000 Marvell M88E1111 EPHY 11
12 USB JTAG Conn. (USB Mini-B) USB JTAG Download Circuit 15
13 DVI Codec and Video Connector Chrontel CH7301C-TF 16,17
14 IIC EEPROM (on backside) ST Micro M24C08-WDW6TP 15
15
Status LEDs
10, 11, 14,
18, 20, 25,
27, 31, 33
a. FMC Power Good 10
b. System ACE CF Status 11
c. FPGA INIT and DONE 14
d. Ethernet PHY Status 18
e. JTAG USB Status 20
f. FPGA Awake 27
g. TI Power Good 31
h. MGT AVCC, DDR3 Term
Pwr Good
33
16
a. User LEDs (4) Red LEDs (active-High) 14
b. User Pushbuttons (4) Active-High 14
c. User DIP Switch (4-pole) 4-pole (active-High) 14
d. User SMA (2) GPIO x2 SMA 13
Table 1-1: SP605 Features (Cont’d)
Number Feature Notes
Schematic
Page
