SP605 Hardware User Guide www.xilinx.com 9
UG526 (v1.9) February 14, 2019
Chapter 1
SP605 Evaluation Board
Overview
The SP605 board enables hardware and software developers to create or evaluate designs
targeting the Spartan®-6 XC6SLX45T-3FGG484 FPGA.
The SP605 provides board features common to many embedded processing systems. Some
commonly used features include: a DDR3 component memory, a 1-lane PCI Express®
interface, a tri-mode Ethernet PHY, general purpose I/O, and a UART. Additional user
desired features can be added through mezzanine cards attached to the onboard high
speed VITA-57 FPGA Mezzanine Connector (FMC) low pin count (LPC) connector.
Features provides a general listing of the board features with details provided in Detailed
Description.
Additional Information
Additional information and support material is located at:
• Spartan-6 FPGA SP605 Evaluation Kit
This information includes:
• Current version of this user guide in PDF format
• Example design files for demonstration of Spartan-6 FPGA features and technology
• Demonstration hardware and software configuration files for the System ACE™ CF
controller, Platform Flash configuration storage device, and linear flash chip
• Reference Design Files
• Schematics in PDF format and DxDesigner schematic format
• Bill of materials (BOM)
• Printed-circuit board (PCB) layout in Allegro PCB format
• Gerber files for the PCB (Many free or shareware Gerber file viewers are available on
the Internet for viewing and printing these files.)
• Additional documentation, errata, frequently asked questions, and the latest news
For information about the Spartan-6 family of FPGA devices, including product highlights,
data sheets, user guides, and application notes, see the S
partan-6 FPGA website.
