62
www.xilinx.com
SP605 Hardware User Gu
ide
UG526 (v1.9) February 14
, 2019
Appendix A:
Default Jumper and Switch Settings
Table A-34:
Default Jumper Settings
Jumper
REFDES
Function
Default
FMC JTAG
Bypass
J19
Exclude FMC LPC connector J2
Jump 1-2
SFP Module
J22
SFP Full BW
Jump 1-2
J44
SFP Enabled
Jump 1-2
SPI Memo
ry
Select
J46
SPI Select SPI X4 Memory U32
Jump 1-2
System ACE
CF Error LED
J60
System ACE CF Error LED DS18 Enabled
Jump 1-2
61
