Chapter 1: Introduction
Board Features
The ZCU104 evaluation board features are listed here. Detailed information for each feature
is provided in Component Descriptions in Chapter 3.
• XCZU7EV-2, FFVC1156 package
•PL V
CCINT
for range in data sheet
• Rectangular form factor for benchtop use
• Configuration from Quad SPI
• Configuration from SD card
• Configuration over JTAG with platform cable USB header
• Configuration over USB-to-JTAG bridge
• IDT 8T49N287A clock chip
°
HDMI_DRU_CLOCK
°
PS_REF_CLK
°
GTR_REF_CLK_USB3
°
GTR_REF_CLK_DP
°
CLK_300
°
GTR_REF_CLK_SATA
°
CLK_125
• PS DDR4 64-bit component (4x16-bit)
• PL DDR4 64-bit SODIMM socket
• PS GTR assignment
°
DisplayPort (two GTRs)
°
USB3 (one GTR)
°
SATA (one GTR)
• PL GTH transceiver assignment (4 of 20 used)
°
High-definition multimedia interface (HDMI®) (three GTH transceivers)
°
FMC LPC DP (one GTH transceiver)
• PL FMC LPC connectivity - full LA bus
• PS MIO: single Quad SPI
• PS MIO: two channels of quad-UART bridge
