Operator Cab
Operation Manual33
Service Brake Pedal
Press the service brake pedal to slow or stop the forklift. The
service brake pedal activates the service brakes on all four (4)
wheels.
Figure 14. Service Brake Pedal
Steering Wheel
Turn the steering wheel left or right to steer the forklift in the
corresponding direction.
Figure 15. Steering Wheel
Horn Button
Press the horn button to sound the horn.
Figure 16. Horn Button
Operator Seat Controls
The operator seat can be adjusted four (4) ways: weight
suspension, lumbar support, fore and aft, and backrest angle.
Figure 17. Operator Seat
Operator Seat
