Yaesu FT-70DR Instruction Manual

Settings
• Set Mode
From the set mode menu, you can customize the various functions of the FT-70DR/DE according to your
preferences.
The ADMS-10 software displays the set mode menu in an easy-to-understand manner where you can
change and save the setting values.
Click the left mouse button on the "Settings" parameter in the "Settings" menu to open the "SetMode”
window.
To change the setting of each item in the window, click the left mouse button on the "▼" icon to show the
dropdown settings list, and then click the desired selection in the list.
Example:
Refer to the "FT-70DR/DE Operating Manual" for the details of each function.
When you have completed editing the settings of the Menu Setting window.
18
ADMS
-
10 Instruction Manual

Yaesu FT-70DR Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Modes	FM, C4FM
Battery	7.4V 1800mAh Li-ion
Waterproof Rating	IP54
Receiver Type	Double-Conversion Superheterodyne
Weight	9.9 oz (with battery)
GPS	No
