Yaesu FT-70DR Instruction Manual

Installing the Driver Software
When a computer is connected with FT-70DR/DE for the rst time, it is necessary to install driver software
in a computer.
1. Connect the FT-70DR/DE to a computer (Refer to the “Connecting the FT-70DR/DE to a computer”).
2. Execute the ADMS-10 (Refer to the “Execute the ADMS-10”).
3. From the menu bar, select “Communications” menu,
and then click on the “COM port Settings”.
4. Click the [Device Manager] button.
5. Under “Other devices” right-click [Unknown device],
then click the [Update Driver].
6. Click [Browse my computer for driver software].
8
ADMS
-
10 Instruction Manual

Yaesu FT-70DR Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Modes	FM, C4FM
Battery	7.4V 1800mAh Li-ion
Waterproof Rating	IP54
Receiver Type	Double-Conversion Superheterodyne
Weight	9.9 oz (with battery)
GPS	No
