Yaesu FT-70DR Instruction Manual

Setup of the ADMS-10
The procedure to install the ADMS-10 on a Windows 7
®
(64 bit) computer is shown below for the purpose
of explanation.
Preparation

Please download the ADMS-10 software from the Yaesu Website for details (http://www.yaesu.com/).

Download the ADMS-10 Programming Software to the same folder, and extract the downloaded zip le.

Start up the computer as an “Administrator” user.
ADMS-10 Programming Software Installation
1. Start up the computer as an “Administrator” user.
2. Double-click the “setup.exe” in the same folder that you have unzip the les.
• When the [.NET Frameworks install] dialog box opens, follow the on-screen instructions to install.
3. The dialog box, which is shown right, will open. Click
the [Next] button.
4. Select the folder to install, then click the [Next] button.
5. Click the [Install] button.
• When the [User Account Control] dialog box opens, click the [Yes] button.
6. When the installation is nished, the dialog box shown
right will open. Click the [Finish] button, to complete
the installation of the software.
5
ADMS
-
10 Instruction Manual

Yaesu FT-70DR Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Modes	FM, C4FM
Battery	7.4V 1800mAh Li-ion
Waterproof Rating	IP54
Receiver Type	Double-Conversion Superheterodyne
Weight	9.9 oz (with battery)
GPS	No
