When installing a spark plug, always clean the
gasket surface and use a new gasket. Wipe
off any grime from the threads and tighten to
the specified torque.
EBU11334
Air filter element cleaning
NOTE:
There is a check hose at the bottom of the air fil-
ter case. If dust or water collects in this hose,
empty the hose and clean the air filter element
and air filter case.
1. Remove the seat. (See page 4-12 for seat
removal and installation procedures.)
2. Remove the air filter case cover by
unhooking the fasteners.
1. Check hose
1. Air filter case cover 2. Fastener (× 4)
3. Remove the air filter element assembly,
and then remove the air filter element
from its frame by turning the lock plate.
8-14
Tightening torque:
Spark plug:
20 Nm (2.0 m0kgf, 14 ft0lbf)
5FK-9-17-03 10/3/04 9:36 PM Page 15
