EBU13611
Spark arrester cleaning
Be sure the exhaust pipe and muffler are cool
before cleaning the spark arrester.
1. Remove the screws.
2. Remove the tailpipe by pulling it out of the
muffler.
3. Tap the tailpipe lightly, and then use a
wire brush to remove any carbon deposits
from the spark arrester portion of the
tailpipe.
4. Make sure the gasket is properly posi-
tioned, then insert the tailpipe into the
muffler and align the screw holes.
5. Install the screws and tighten them.
8-17
1. Screw (× 3)
