EBU03021
Idle speed adjustment
NOTE:
A diagnostic tachometer must be used for this
procedure.
NOTE:
The throttle cables and carburetor synchro-
nization must be set properly before adjusting
the idle speed.
1. Adjust the pilot air screws.
8 Turn in both pilot air screws until they
lightly seat.
8 Turn out both pilot air screws to specifi-
cation. (Refer to the “Carburetor set-
tings” section.)
1. Pilot air screw
2. Remove the seat.
3. Start the engine and warm it up for a few
minutes at approximately 1,000 to 2,000
r/min.
8-26
