EBU00064
Throttle OverRide System
If during operation, the carburetor or the throt-
tle cable should malfunction and will not close
fully, take your thumb off the throttle lever.
The Throttle OverRide System immediately
cuts off the ignition.
EBU11590
Speed limiter
The speed limiter keeps the throttle from fully
opening, even when the throttle lever is pushed
to the maximum. Turning in the adjusting screw
limits the maximum engine power available and
decreases the maximum speed of the ATV.
1. Locknut 2. Adjusting screw
a. No more than 12 mm (0.47 in)
4-4
POTENTIAL HAZARD
Continuing to ride the ATV after the
Throttle OverRide System (T.O.R.S.) has
stopped the engine.
WHAT CAN HAPPEN
Riding with a malfunction increases the
chance for an accident and injury.
HOW TO AVOID THE HAZARD
Make sure that the cause of the malfunc-
tion is corrected before restarting the
engine. You should have the ATV
inspected by a Yamaha dealer.
q
WARNING
