Yamaha F30 User Manual

Operation
72
3. Push the power trim and tilt switch “ ”
(down) to lower the outboard motor to
the desired position.
EMU28063
Shallow water
EMU28082
Hydro tilt models
The outboard motor can be tilted up partially
to allow operation in shallow water.
WARNING
EWM00272
 Run the boat at the lowest possible
speed when using the shallow water
cruising system.
 Use extra care when operating in re-
verse. Too much reverse thrust can
cause the outboard motor to lift out of
the water, increasing the chance of ac-
cident and personal injury.
NOTICE
ECM00261
Do not tilt the outboard motor up so that
the cooling water inlet on the lower unit is
above the surface of the water when set-
ting up for and cruising in shallow water.
Otherwise severe damage from overheat-
ing can result.
EMU32841
Procedure for hydro tilt models
1. Place the gear shift lever in neutral.
DN
ZMU01936
DN
ZMU06410
ZMU03646
6BG-9-3F-E0.book 72 ページ ２０１８年１１月１日 木曜日 午後５時１分
©2020 Yamaha Motor Corporation

Yamaha F30 Specifications

General

Engine Type	4-Stroke, SOHC
Prop Shaft Horsepower	30 hp
Full Throttle RPM Range	5000-6000 rpm
Starting System	Electric
Gear Ratio	2.08:1
Lubrication	Wet sump
Gear Shift	F-N-R
Displacement	747 cc
Fuel Induction System	EFI (Electronic Fuel Injection)
Ignition System	TCI
Shaft Length	15 in, 20 in
Steering	Remote
Bore x Stroke	65.0 mm x 75.0 mm (2.6 x 3.0 in.)
