34 PSR-S910/S710 Owner’s Manual
Voices – Playing the keyboard –
1
The TRANSPOSE [-]/[+] buttons transpose the overall pitch of the instrument (the
keyboard sound, Style playback, Song playback, and so on) in semitone steps. Press
the [+] and [-] buttons simultaneously to instantly reset the transpose value to 0.
The UPPER OCTAVE [-]/[+] buttons allow the pitch of the RIGHT 1 and 2 parts to
be shifted up or down by one octave. Press the [+] and [-] buttons simultaneously to
instantly reset the octave value to 0.
Use the PITCH BEND wheel to bend notes up (roll the wheel away from you) or
down (roll the wheel toward you) while playing the keyboard. The Pitch Bend is
applied to all the keyboard parts (RIGHT 1, 2 and LEFT). The PITCH BEND wheel
is self-centering and will automatically return to normal pitch when released.
The maximum pitch bend range can be changed on the Mixing Console display:
[MIXING CONSOLE] → TAB [EE
EE
][FF
FF
] TUNE → [H] PITCH BEND RANGE.
Transposing the Pitch of the Keyboard
The Transpose functions do not affect
the Drum Kit or SFX Kit Voices.
You can also change the transpose
settings in the MIXING CONSOLE
display: [MIXING CONSOLE]→ TAB
[EE
EE
][FF
FF
] TUNE → [1 ▲▼] – [3 ▲▼]
TRANSPOSE.
Default Pitch setting
By default, the reference pitch of the entire instrument is set to 440.0 Hz, and
the scale to equal temperament. You can change the pitch and scale from
[FUNCTION] → [A] MASTER TUNE/SCALE TUNE.
You can also adjust the pitch for each part (keyboard parts, Style parts and
Song parts) on the TUNE page of the Mixing Console display (page 79).
For details, refer to the Reference Manual on the website.
Using the Wheels
Using the Pitch Bend Wheel
The effects caused by using the
PITCH BEND Wheel may not be
applied to the LEFT part during Style
playback depending on the Style set-
ting.
