DESCRIPTION
EAU10420
Right view
1. Tail/brake light (page 6-27)
2. Carrier (page 3-9)
3. Fuel tank cap (page 3-4)
4. Seat (page 3-7)
5. Front brake master cylinder (page 6-19)
6. Headlight (page 6-25)
7. Spark plug (page 6-8)
8. Centerstand (page 6-21)
9. Muffler
12
3
6
78
9
4
5
