PERIODIC MAINTENANCE AND MINOR REPAIR
9. Install the kickstarter lever by in-
stalling the bolt, then tightening the
bolt to the specified torque.
Tightening torque:
Kickstarter bolt:
23 Nm (2.3 m•kgf, 16.6ft•lbf)
EAU21251
Carburetor
The carburetor is an important part of
the engine and its emission control sys-
tem, which requires very sophisticated
adjustment. Therefore, carburetor adjust-
ments should be left to Yamaha dealer,
who has the necessary professional
knowledge and experience.
Carburetor<IXE>
Throttle cable free play, checking<IXE>
EAU21382
Checking the throttle cable
free play
The throttle cable free play should mea-
sure 3.0~5.0 mm (0.12~0.2 in) at the
throttle grip. Periodically check the
throttle cable free play and, if necessary,
have a Yamaha dealer adjust it.
5YR-F8199-14_ch6.pmd 2007/05/24, 19:5814

Yamaha VINO 125 Specifications

General

Displacement	125cc
Fuel System	Fuel Injection
Transmission	V-belt automatic
Front Suspension	Telescopic fork
Rear Suspension	Unit Swing
Rear Brake	Drum
Bore x Stroke	52.4 mm x 57.9 mm
Engine Type	4-stroke, SOHC
Front Brake	Single disc
Seat Height	30.3 inches
Starter System	Electric
