SPECIFICATIONS
Manufacturer/model
CHENG SHIN/C-922L
Rear tire
Type
Tubeless
Size
3.50-10 51J
Manufacturer/model
CHENG SHIN/C-6007
Loading
Maximum load
144 kg (317 lb)
Tire air pressure (measured on cold tires)
Loading condition
0-90 kg (0-198 lb)
Front
150 kPa (22 psi) (1.50 kgf/cm
2
) (1.50 bar)
Rear
200 kPa (29 psi) (2.00 kgf/cm
2
) (2.00 bar)
Loading condition
90 kg - maximum load
Front
150 kPa (22 psi) (1.50 kgf/cm
2
) (1.50 bar)
Rear
225 kPa (33 psi) (2.25 kgf/cm
2
) (2.25 bar)
Front wheel
Wheel type
Cast wheel
Rim size
J10 x MT2.5
Rear wheel
Wheel type
Cast wheel
Rim size
J10 x MT2.5
Front brake
Type
Single disc brake
Operation
Right hand operation
Recommended fluid
DOT 3 or 4
Rear brake
Type
Drum brake
Operation
Left hand operation
Front suspension
Type
Telescopic fork
Spring/shock absorber type
Coil spring/oil damper
Wheel travel
59.0 mm (2.32 in)
Rear suspension
Type
Unit swing
Spring/shock absorber type
Coil spring/oil damper
Wheel travel
54.0 mm (2.13 in)
Electrical system
Ignition system
CDI
Charging system
CDI magneto
Battery
Model
GTX7A-BS / YTX7A-BS
Voltage, capacity
12 V, 6.0 Ah
Headlight
Bulb type
Halogen bulb
Bulb voltage, wattage x quantity
Headlight
12 V, 60 W/55.0 W x 1
Tail/brake light
12 V, 8.0 W/27.0 W x 1
Front turn signal light
12 V, 10.0 W x 2
Rear turn signal light
12 V, 10.0 W x 2
License plate light
12 V, 8.0 W x 1
Meter lighting
14 V, 3.0 W x 1
Meter lighting (fuel meter)
14 V, 3.0 W x 1
High beam indicator light
14 V, 3.0 W x 1
Turn signal indicator light
12 V, 1.7 W x 1
Fuses
Main fuse
10.0 A
5YR-F8199-14_ch8.pmd 2007/05/24, 19:582
