SPECIFICATIONS
EAU26320
SPECIFICATIONS
Specifications<IXE>
EAU2633K
Dimensions
Overall length
1755 mm (69.1 in)
Overall width
699 mm (27.5 in)
Overall height
1063 mm (41.9 in)
Seat height
759 mm (29.9 in)
Wheelbase
1230 mm (48.4 in)
Ground clearance
95 mm (3.74 in)
Minimum turning radius
1800 mm (70.9 in)
Weight
With oil and fuel
109.0 kg (240 lb)
Engine
Engine type
Air cooled 4-stroke, SOHC
Cylinder arrangement
Forward-inclined single cylinder
Displacement
125.0 cm
3
Bore x stroke
51.5 x 60.0 mm (2.03 x 2.36 in)
Compression ratio
9.80 :1
Starting system
Electric starter and kickstarter
Lubrication system
Wet sump
Engine oil
Type
YAMALUBE 4, SAE10W30 or SAE20W40
10 30 50 70 90
110
0
130
˚
F
-10 0 10 20 30
40
-20
50
˚
C
or SAE 10W-30
YAMALUBE 4 (10W-30)
YAMALUBE 4 (20W-40)
or SAE 20W-40
Recommended engine oil grade
API service SG type or higher, JASO stan-
dard MA
Engine oil quantity
Periodic oil change
1.00 L (1.06 US qt) (0.88 Imp.qt)
Final transmission oil
Type
SAE85W-140(GL5)
Quantity
0.13 L (0.14 US qt) (0.11 Imp.qt)
Air filter
Air filter element
Oil-coated paper element
Fuel
Recommended fuel
Unleaded gasoline only
Fuel tank capacity
4.7 L (1.24 US gal) (1.03 Imp.gal)
Carburetor
Manufacturer
Mikuni
Type x quantity
BS26 x 1
Spark plug (s)
Manufacturer/model
NGK/CR7E
Spark plug gap
0.7-0.8 mm (0.028-0.031 in)
Clutch
Clutch type
Dry, centrifugal automatic
Transmission
Primary reduction system
Helical gear
Primary reduction ratio
40/15 (2.666)
Secondary reduction system
Spur gear
Secondary reduction ratio
38/13 (2.923)
Transmission type
V-belt automatic
Operation
Centrifugal automatic type
Chassis
Frame type
Steel tube backbone
Caster angle
32.00 degree
Trail
75.0 mm (2.95 in)
Front tire
Type
Tubeless
Size
3.50-10 51J
