4 Parameter Copy Mode
4.2.2 Write-in Parameters (OP → SERVO)
4-6
4.2.2 Write-in Parameters (OP → SERVO)
The selected block of parameters saved in the digital operator are written into the
SERVOPACK.
(1) Operating Procedure
Step Display after Operation Keys Operation
1
Open the parameter copy mode menu
display, and select “OP → SERVO”
using the
or Key.
The blinking menu is one that is being
selected.
2
Press the
Key.
The display changes to the parameter
block selection display.
3
Press the
or Key to select
a parameter block (00 to 06) of the digi-
tal operator that is to be written into the
SERVOPACK.
4
Press the
Key.
The display changes to the execution dis-
play.
5
Press the Key to start writing
parameters into the SERVOPACK.
Note: While the power to the servomo-
tor is ON (RUN) and the Write
Prohibited Setting (Fn010 =
0001) is set, the Key is
disabled and “Not Available” is
displayed if it is pressed.
1:SERVO→ OP
2:OP→ SERVO
3:VERIFY
4:LIST
BB − COPY−
00:SGDV− R70
01:∗∗∗∗
02:∗∗∗∗
03:∗∗∗∗
BB − OP→ SERVO−
00:SGDV− R70
01:∗∗∗∗
02:∗∗∗∗
03:∗∗∗∗
BB − OP→ SERVO−
00:SGDV− R70
Start : [WRITE]
Return: [MODE]
BB − OP→ SERVO−
00:SGDV− R70
Reading
Parameters..
<< OP >>
BB − OP→ SERVO−
To Next Page
Loading...
