3.2.17 Software Version Display (Fn012)
This function is used to check the SERVOPACK and encoder software version num-
bers.
(1) Preparation
There are no tasks that must be performed before the execution.
(2) Operating Procedure
Use the following procedure.
Step Display after Operation Keys Operation
1
Press the Key to view the main
menu for the utility function mode.
Use the
or Key to move
through the list and select Fn012.
2
Press the
Key. The display
changes to the Fn012 execution dis-
play.
The software versions of the SERVO-
PACK and the connected encoder will
appear.
Note: If the servomotor is not con-
nected, “Not connect” is dis-
played.
3
Press the Key. The display
returns to the main menu of the utility
function mode.
