Yealink SIP-T42G User Manual

User Guide for the SIP-T42G IP Phone
16
To connect the PoE for the SIP-T42G IP phone:
1. Connect the Ethernet cable between the Internet port on the phone and an
available port on the in-line power switch/hub.
Note
After your phone is powered on, the system boots up and performs the following steps:
Automatic Phone Initialization
The phone finishes the initialization by loading the saved configuration. The LCD screen
displays “Welcome Initializing Please wait…” during the initialization.
DHCP (Dynamic Host Configuration Protocol)
The phone attempts to contact a DHCP server in your network to obtain valid IPv4
network settings (e.g., IP address, subnet mask, default gateway address and DNS
address) by default.
After the phone finishes the initialization, the sign-in screen appears on the LCD screen.
Note
Skype for Business users are authenticated against Microsoft Active Directory Domain
If in-line power is provided, you don’t need to connect the phone to the power adapter.
Make sure the switch/hub is PoE-compliant.
The phone can also share the network with another network device such as a PC
(personal computer).This is an optional connection.
Important! Do not remove power to the phone while it is updating firmware and
configurations.
If your network does not use DHCP, proceed to Basic Network Settings on page 30.

Yealink SIP-T42G Specifications

General

Power requirements	100-240V, DC 5V
Power over Ethernet (PoE)	Yes
Touchscreen	-
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Voice codecs	G.711, G.723, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Grey
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	175 mm
Width	212 mm
Height	189 mm
