TI 33K01B10-50E
4.4 HardwareModicationandAddition
HISandVnet/IP(*1)thatareinstallednewlyarenotdescribedherein,sincetheyareidentiedas
the CENTUM VP product.
*1: Vnet/IP Interface Card, cable and network switch.
4.4.1 Modifying FCS
For the conventional FCS, upgrade the SCN/IO nest to FCU/Node unit of CENTUM VP.
To upgrade from CENTUM-XL, use the Cabinet Utility Kit (ACUKT2). This kit contains a set of
partsrequiredforthespeciedupdate.Foractualupgradework,youalsoneedFCU(AFV30),
Node Unit for FIO and associated cables besides this Kit.
SEE
ALSO
For ACUKT2, refer to Cabinet Utility Kit (GS 33K50K21-50E).
WhenupgradingfromCENTUMV,theACUKT2isnotyetconguredforsuchupgrade.Formore
information, contact the sales department of Yokogawa Electric Corporation.
The following table shows the major components of ACUKT2.
Table Parts contained in ACUKT2
Name Model name Quantity Remark
Distribution Board Frame with HKU – 1 –
Main Distribution Board – 1 –
Fan Power Supply Unit – 2 –
Roof Fan Interface Board and Cover – 1 for each –
SC Fan Interface Board and Cover – 1 for each –
DC-power Distribution Board – 1 –
Relay Terminal – 1 –
Node Fan Unit ANFAN – Optional
Upright Distribution Unit – – Optional
Cable – – –
