5. System Functions After Upgrade
5-4
TI 33K01B10-50E
5.1.3 Comparison of Continuous Control Function
The table below shows a comparison of the continuous control function models between the
CENTUM V, CENTUM-XL, and CENTUM VP systems.
Table Comparison of Continuous Control Function
Block type
Model
Description
CENTUM V CENTUM-XL Upgraded FCS
Input
indicator
7PV PVI PVI Input indicator
7PV-DV PVI-DV PVI-DV Input indicator with deviation alarms
Controller
7DC-D5
PID PID
PID controller
The same control action can be obtained by changing
the control algorithm and gap action using the builder.
7DC-N5
7DC-D6
7DC-N6
– PI-HLD PI-HLD Sampling PI controller
7DC-B5 PID-BSW PID-BSW Controller with batch switch
7DC-C2 ONOFF ONOFF 2-position on/off controller
7DC-C3 ONOFF-G ONOFF-G 3-position on/off controller
7DC-C9 PID-TP PID-TP Time-proportional on/off controller
7DC-D3 PD-MR PD-MR Proportional controller
7DC-D9 PI-BLEND PI-BLEND Blending controller
– PID-STC PID-STC Self-tuning PID controller
Manual
operation
unit
7ML-ND MLD MLD Manual loader
7ML MLD-PVI MLD-PVI Manual loader with input indicator
7ML-SW
MLD-SW MLD-SW Manual loader with auto/man switch
7ML-XN
7MC-C2 MC-2 MC-2 2-position motor control unit
7MC-C3 MC-3 MC-3 3-position motor control unit
Signal set
unit
7RS RATIO RATIO Ratio set unit
7PG
PG-L13
PG-L13
6-zone program set unit (Substitute PG-L13.)
7PG-BR 13-zone program set unit
7PG-SP PG-S13 13-step program set unit (Substitute PG-L13.)
7BS BSETU
BSETU-2
Batch set unit
– BSETU-2
Batchsetunitforowmeasurement
– BSETU-3 BSETU-3 Batch set unit for weight measurement
Signal
limiter
7RL VELLIM VELLIM Velocity limiter
Signal
selector
7SS-S-H/M/L SS-H/M/L SS-H/M/L Signal selector
7SS-A-H/M/L AS-H/M/L AS-H/M/L Autoselector
7RD SS-DUAL SS-DUAL Dual signal selector
Data link
7SL-DT SDL
ADL
Station data link
– SDL-2 Station data link for setting by communication
YS80
SLCD SLCD SLCD SLCD indicating controller
SLPC SLPC SLPC SLPC programmable controller
SLMC SLMC SLMC SLMC programmable controller with pulse-width output
SMST-111 SMST-111 SMST-111
SMST-111 auto/manual station with push-button setpoint
setting
SMST-121 SMST-121 SMST-121
SMST-121 auto/manual station with manipulated output
lever
SMRT SMRT SMRT SMRT ratio set unit
YS BCS
SBSD SBSD SBSD SBSD batch set unit
SLCC SLCC SLCC SLCC blending controller
SLBC SLBC SLBC SLBC batch controller
STLD STLD STLD STLD totalizer
Alarm – ALM-R ALM-R Representative alarm unit
Mar. 27, 2015-00
