YOKOGAWA Centum-XL User Manual

Appendix 5. Glossary
App.5-1
TI 33K01B10-50E
Appendix 5. Glossary
This is a glossary of abbreviations and acronyms about Yokogawa products that are mentioned
in this document.
Table Glossary(1/2)
Abbreviation
or Acronym
Description
ACG CENTUM VP Communication gateway with supervisory computer
ANB10S, ANB10D CENTUM VP Node unit for FIO (Single/Duplexed)
ANR10S, ANR10D CENTUM VP Remote node unit for FIO (Single/Duplexed)
APCS
Advanced Process Control Station (Station on a PC platform, mainly intended to
perform plant advanced control)
BCV-H Converter between V net and HF bus
BRAIN communication Function to communicate with BRAIN Series products supported with CENTUM-XL
CCMS CENTUM V Computer station
CFBS2
CENTUMVCompacteldcontrolstation
CFCS2, CFCD2 CENTUM V Field control station (Single/Duplexed)
CFGW CENTUM V Field gateway unit
CFSS, CFSD CENTUM V Field control station for sequence control (Single/Duplexed)
CGWU CENTUM V Gateway unit for communication with higher-level systems (-1, -2, -3 models)
COPSV CENTUM V Operation & monitoring station
ECGWZ,ECGW2,
ECGW3
CENTUM-XL Gateway units for communication with higher-level systems
ECMP CENTUM-XL Computer stations
EFCS, EFCD CENTUM-XL Field control station (-S1, -H2, -H4 models) (Single/Duplexed)
EFGW CENTUM-XL Field gateway unit
EFUS, EFUD
CENTUM-XLCompacteldcontrolstation(Single/Duplexed)
EMCS, EMCD CENTUM-XL Master control station (Single/Duplexed)
ENG CENTUM VP Engineering station
ENGS CENTUM-XL Engineering station
EOPS CENTUM-XL Operation & monitoring station
ER bus
I/O bus that connects remote connection card installed in Node Unit for FIO to
Remote Node Unit for FIO
ESB bus I/O bus that connects CPU in Field Control Unit (SCN) to Node Unit for FIO.
Exaopc OPC interface package
Exapro Expert system building support tool
Exaquantum Plant information management system
FCS Field Control Station (generally used for CENTUM series.)
FCU
Fieldcontrolunit;theCPUofanFCSoftheCENTUMVP.
FFCS, FFCD CENTUM VP Field control station (Single/Duplexed)
FIO
I/OforCENTUMVP’seldcontrolstation
FMS Field Monitoring Station (generally used for CENTUM series.)
HF bus Control bus used in CENTUM V and CENTUM-XL systems
HIS CENTUM VP Operation & monitoring station
HKU
House Keeping Unit (Collects alarm information, changes and collects SC setting
informationinCENTUM-XLeldcontrolstation.)
IOM I/O Module for CENTUM VP
KFCS Field control station for CENTUM VP
KFCS-V
An FCS which was of the CENTUM V and has been upgraded to CENTUM VP's FCS
with16-MBRAM;alsoreferredtoasupgradedFCS-V.
KFCS2-V
An FCS which was of the CENTUM V and has been upgraded to CENTUM VP's FCS
with32-MBRAM;alsoreferredtoasupgradedFCS2-V.
KFCS-XL
An FCS which was of the CENTUM-XL and has been upgraded to CENTUM VP's
FCSwith16-MBRAM;alsoreferredtoasupgradedFCSXL.
KFCS2-XL
An FCS which was of the CENTUM-XL and has been upgraded to CENTUM VP's
FCSwith32-MBRAM;alsoreferredtoasupgradedFCS2-XL.
