4. Procedure and Details of Upgrade
4-9
TI 33K01B10-50E
4.4.3 Upgrading the Existing I/O Card Unit
Upgrade of the existing I/O card unit shall be carried out into the I/O modules as shown below.
Table I/O modules after upgrade
Model of existing I/O cards & multiplexer cards
Model of I/O modules
for Upgrade
KS interface
adapter
MAC2 (Analog input/output: 8 points each) AAB841 ATM4A
PAC(Pulsetraininput:8points;Analogoutput:8points) AAP849 –
VM1 (Analog input: 16 points) AAV141 ATK4A
VM2 (Analog input 8 points, Analog output 8 points) AAB841 ATV4A
VM4 (Analog output: 16 points) AAV542 ATK4A
PM1 (Pulse train input: 16 points) AAP149 –
ST2(DI:16points;DO:16points) ADV859(*1) –
ST3 (DI, 32 points) ADV159(*1) –
ST4 (DO, 32 points) ADV559(*1) –
ST5(DI:32points;DO:32points) ADV869(*1) –
ST6 (DI, 64 points) ADV169(*1) –
ST7 (DO, 64 points) ADV569(*1) –
PB5 (Multi-point pushbutton input) ADV159 –
RS4 (RS-232C communication card)
ALR111
(Cable also must be changed)
–
MX2 (Non-isolated, mV, TC, 32 points) AAT145 (2 modules) –
MX3 (Isolated, mV, TC, 16 points) AAT145 –
MX4 (Non-isolated, voltage, 32 points) AAV142 (2 modules) ATK4A
MX5 (Isolated, voltage, 16 points) (AAV142, non-isolated) (AAV142, non-isolated) ATK4A
MX6 (RTD, 32 points) AAR145 (2 modules) –
MAC3 (Analog input/Output: 8 points each, for power supply) (*2) –
PB6 (Multi-point push button input, 16 points) ADV159 –
LD1 (Loop display interface card, CLDU ~ MAC2) (*3) –
LCU (Loop communication card, ULDU: 4 units) (*3) (*4) –
LCS (Loop communication card, YS80: 8 units) ALR121(*5) –
*1: IntheCENTUMVP,theinput/outputtypeisspeciedforeachterminal(i.e.,point)ofacontactinput/outputmodule;anoutput
type setting for an odd terminal may take effect on the next even terminal. For details, see GS 33K50F70-50E for Digital I/O
Modules (for FIO).
*2: Simply updating to AAB841 is not enough for this setup. Interactive operation with a manual station is necessary.
*3: CLDU and ULDU cannot be used. Substitute with a YS instrument.
*4: Replace with the communication card of FIO plus YS1000.
*5: For connection between an LCS card and a star-type YS instrument, replacement with star type is not possible in updating to
FIO. Since SCIU is currently under order stop, FIO needs to be formed as a daisy chain.
Mar. 27, 2015-00
