137
JOHNSON CONTROLS
FORM 201.21-NM1 (1223)
COMPONENT LOCATIONS (CON'T)
FIG. 13 - CHILLER CONTROL BOARD, RELAY BOARDS, MICROGATEWAY,
AND OPTIONAL CIRCUIT BREAKER
LD10579
MICROGATEWAY
(OPTIONAL)
CHILLER
CONTROL
BOARD
RELAY BOARD #1
RELAY BOARD #2
OPTIONAL
CIRCUIT BREAKER
(Standard Unit will have terminal blocks.
Input power to the chiller will
be connected here (see FIG.-17)).
6
