PRESSURE TRANDUCER OUTPUT VOLTAGE
Suction Pressure
Transducer
(125 PSIG)
Discharge Pressure
Transducer
(275 PSIG)
Discharge Pressure
Transducer
(275 PSIG)
Pressure Voltage Pressure Voltage Pressure Voltage
0 0.50 0 0.50 140 2.54
5 0.66 5 0.57 145 2.61
10 0.82 10 0.65 150 2.68
15 0.98 15 0.72 155 2.75
20 1.14 20 0.79 160 2.83
25 1.30 25 0.86 165 2.90
30 1.46 30 0.94 170 2.97
35 1.62 35 1.01 175 3.05
40 1.78 40 1.08 180 3.12
45 1.94 45 1.15 185 3.19
50 2.10 50 1.23 190 3.26
55 2.26 55 1.30 195 3.34
60 2.42 60 1.37 200 3.41
65 2.58 65 1.45 205 3.48
70 2.74 70 1.52 210 3.55
75 2.90 75 1.59 215 3.63
80 3.06 80 1.66 220 3.70
85 3.22 85 1.74 225 3.77
90 3.38 90 1.81 230 3.85
95 3.54 95 1.88 235 3.92
100 3.70 100 1.95 240 3.99
105 3.86 105 2.03 245 4.06
110 4.02 110 2.10 250 4.14
115 4.18 115 2.17 255 4.21
120 4.34 120 2.25 260 4.28
125 4.50 125 2.32 265 4.35
130 2.39 270 4.43
135 2.46 275 4.50
MAINTENANCE
TABLE 32 - PRESSURE TRANSDUCER INPUT VOLTAGE (MEASURED SIGNAL TO RETURN AT THE TRANSDUCER)
