272

JOHNSON CONTROLS

FORM 201.21-NM1 (1223)

UNIT SETUP MODE

MICRO PANEL

Unit Setup Mode will allow the programming all of the

programmable values that the user should never change.

These will either be programmed at the factory or by

service personnel on the job.

TABLE 19 - UNIT SETUP PROGRAMMABLE VALUES

SETUP MODE VALUE PRAGRAMMABLE RANGE DEFAULT

Sys 1 Number of Cond Fans 4 to 6 6

Sys 2 Number of Cond Fans 4 to 6 6

Sys 3 Number of Cond Fans 4 to 6 6

Sys 4 Number of Cond Fans 4 to 6 6

Compressor 1 Operating hours 0 to 99,999 0

Compressor 2 Operating hours 0 to 99,999 0

Compressor 3 Operating hours 0 to 99,999 0

Compressor 4 Operating hours 0 to 99,999 0

Compressor 1 Starts 0 to 99,999 0

Compressor 2 Starts 0 to 99,999 0

Compressor 3 Starts 0 to 99,999 0

Compressor 4 Starts 0 to 99,999 0

Clear History Bu󰀨ers Yes/ No -

Remote Temp Reset Option Disabled/Enabled Disabled

Remote Current Limit Option Disabled/Enabled Disabled

Sound Limit Option Disabled/Enabled Disabled

Remote Inputs Service Time 5 Min - 60 Min 15 Min

Sys 1 Motor Sensor to Ignore See Below None

Sys 2 Motor Sensor to Ignore See Below None

Sys 3 Motor Sensor to Ignore See Below None

Sys 4 Motor Sensor to Ignore See Below None

The following messages will be displayed for the Unit

Setup Mode in the order they appear. The rst group

of displays relates to setup parameters that relate to unit

conguration and factory setpoints.
