MAINTENANCE INSTRUCTIONS
A 162 A 163 A 164
INSPECTION AND OIL EXCHANGE IN
TRANSMISSION, DIFFERENTIAL
HOUSING, AND BULL GEAR
HOUSINGS (PORTALS)
The oil level is inspected by oil dipstick
integrated in filler cap (5), that is located
on the left rear part of differential case.
Inspect the oil level at stopped engine,
the oil must be within the range of oil
dipstick flattened part.
Damaged or lost plug must be
exchanged by an original plug
only this will assure breathing of
transmission case.
DRAINING AND INSPECTION OPEN-
INGS
1. Transmission draining plug.
2. Differential case draining plug.
3. Bull gear housing draining plug.
4. Inspection and filling plug of bull gear
housing (valid for standard position of
bull gear housing)
5. Inspection and filling plug of trans-
mission.
6. Draining plug of right and left brake
chamber.
7. Brake chamber oil dipstick.
8. Front wheel drive gearbox draining
plug.
