ABB 2 Series User Manual

4 “Operation and installation manual” - “Terra 360 Series 2 - CE”
EN
6. Installation
6.1 Installation of the EVSE - Terra 60 44
6.1.1 Floor space requirements - Terra 60 44
6.1.2 Prepare the foundation - Terra 60 45
6.1.3 Remove the base cover - Terra 60 46
6.1.4 Open the cable glands - Terra 60 46
6.1.5 Route the cables - Terra 60 46
6.1.6 Install the base - Terra 60 47
6.1.7 AC cables preparation - Terra 60 47
6.1.8 Install the base cover - Terra 60 47
6.1.9 Install the EVSE on the base - Terra 60 48
6.2 Installation of the EVSE - Terra 360 Series 2 50
6.2.1 Floor space requirements - Terra 360 50
6.2.2 Prepare the foundation - Terra 360 50
6.2.3 Assembly the base - Terra 360 51
6.2.4 Remove the base covers - Terra 360 51
6.2.5 Open the AC input cable inlets - Terra 360 52
6.2.6 Open the cable glands - Terra 360 52
6.2.7 Route the cables - Terra 360 52
6.2.8 Install the base - Terra 360 53
6.2.9 AC cables preparation - Terra 360 53
6.2.10 Install the base covers - Terra 360 54
6.2.11 Install the EVSE on the base - Terra 360 54
7. Electrical connection
7.1 Protective earth (PE) 56
7.1.1 Connect the PE wire 57
7.2 AC input 57
7.2.1 Supported low voltage network types 57
7.2.2 External AC input protections 59
7.2.3 Connect the AC wires - Terra 60 60
7.2.4 Connect and seal the AC wires - Terra 360 60
7.3 Ethernet 61
7.3.1 Connect the ethernet cable - Terra 60 61
7.4 Tilt sensor (optional) 62
7.4.1 Connect the tilt sensor 63
8. Operation and correct use
8.1 Prepare for commissioning 64
8.2 Prepare before use 65
8.3 Charge session 65
8.3.1 Charge an EV 65
8.3.2 Stop a charge session 66
9. Maintenance and troubleshooting
9.1 Maintenance schedule for the owner 67
9.2 Troubleshooting 68
10. Technical data
10.1 Technical data 69
10.1.1 Technical data table - Terra 60 69
10.1.2 Technical data table - Terra 360 71
10.2 Cable specifications 73
10.3 Torque specification 73
10.4 Charging interface 74
10.5 Output current Vs output voltage curve 75
10.5.1 Output current Vs output voltage - Terra 60 75
10.5.2 Output current (peak) Vs output voltage - Terra 360 75
10.6 Output power Vs output voltage curve 76
10.6.1 Output power Vs output voltage - Terra 60 76
10.6.2 Output power (peak) Vs output voltage - Terra 360 76
10.7 Height of user operable elements 77
11. Attachments
11.1 Footprint - Terra 60 79
11.2 Footprint - Terra 360 80
11.3 Prefabricated foundation - Terra 60 81
11.4 Prefabricated foundation - Terra 360 82
11.5 Messrichtigkeitshinweise gemäß
Baumusterprüfbescheinigung 83
