178 Parameters
Reduced Reduced ID run. This mode should be selected instead of the
Normal or Advanced ID Run if
• mechanical losses are higher than 20% (ie. the motor
cannot be de-coupled from the driven equipment), or if
• flux reduction is not allowed while the motor is running
With this ID run mode, the resultant motor control in the field
weakening area or at high torques is not necessarily as
accurate as motor control following a Normal ID run. Reduced
ID run is completed faster than the Normal ID Run (< 90
seconds).
Note: Check the direction of rotation of the motor before
starting the ID run. During the run, the motor will rotate in the
forward direction.
WARNING! The motor will run at up to approximately
50…100% of the nominal speed during the ID run.
ENSURE THAT IT IS SAFE TO RUN THE MOTOR
BEFORE PERFORMING THE ID RUN!
2
Standstill Standstill ID run. The motor is injected with DC current. With
an AC induction (asynchronous) motor, the motor shaft is not
rotated. With a permanent magnet motor, the shaft can rotate
up to half a revolution.
Note: This mode should be selected only if the Normal,
Reduced or Advanced ID run is not possible due to the
restrictions caused by the connected mechanics (e.g. with lift
or crane applications).
3
Autophasing Not applicable 4
Current
measurement
calibration
Requests current measurement calibration, ie. identification
of current measurement offset and gain errors. The
calibration will be performed at next start.
5
Advanced Advanced ID run. Only for frames R6…R8.
Guarantees the best possible control accuracy. The ID run
takes a very long time to complete. This mode should be
selected when top performance is needed across the whole
operating area.
Note: The driven machinery must be de-coupled from the
motor because of high torque and speed transients that are
applied.
WARNING! The motor may run at up to the maximum
(positive) and minimum (negative) allowed speed
during the ID run. Several accelerations and
decelerations are done. The maximum torque, current and
speed allowed by the limit parameters may be utilized.
ENSURE THAT IT IS SAFE TO RUN THE MOTOR BEFORE
PERFORMING THE ID RUN!
6
Adaptive Adaptive ID run. Initially, drive runs in Standstill ID run mode
and then refines the motor parameters during the normal
operation. This helps to achieve more optimal performance.
Note: This is applicable for R0...R5 frames only.
7
99.14 Last ID run
performed
Shows the type of ID run that was performed last. For more
information about the different modes, see the selections of
parameter 99.13 ID run requested.
None
None No ID run has been performed. 0
Normal Normal ID run. 1
Reduced Reduced ID run. 2
Standstill Standstill ID run. 3
No. Name/Value Description Def/FbEq16
ACQ80 FW.book Page 178 Thursday, February 14, 2019 11:33 AM
