Additional parameter data 193
58.102 Data I/O 2 Analog
src
--1 = 1
58.103 Data I/O 3 Analog
src
--1 = 1
58.104 Data I/O 4 Analog
src
--1 = 1
58.105 Data I/O 5 Analog
src
--1 = 1
58.106 Data I/O 6 Analog
src
--1 = 1
58.107 Data I/O 7 Analog
src
--1 = 1
…… ………
58.114 Data I/O 14 Analog
src
--1 = 1
79 Start stop control
79.01 Solar status word1 PB 0b0000...0b1111 -1 = 1
79.02 Solar status word2 PB 0b0000...0b1111 -1 = 1
79.10 Operating mode List 0, 1, 2, 3, 4, 5 -1 = 1
79.11 Manual input source 1 List 0...7 -1 = 1
79.12 Manual input source 2 List See parameter
79.11 -1 = 1
79.15 Enable tank level operation Binary src 0…7 - 1 = 1
79.17 Tank low sensor Binary src 0…7 - 1 = 1
79.18 Tank high sensor Binary src 0…7 - 1 = 1
79.31 Pump start time Real 00:00:00...23:59:59 -1 = 1
79.32 Pump stop time Real 00:00:00...23:59:59 -1 = 1
79.40 MPPT reference List 0...6 -1 = 1
79.41 Start DC voltage Real 225...800 V -
79.42 PV cell min voltage Real 225...800 V -
79.43 PV cell max voltage Real 225...800 V -
79.51 Pump minimum speed Real 0...3000 rpm -
79.52 Pump maximum speed Real 0...3000 rpm -
79.56 Boost voltage Real 225...600 V -
79.57 Boost factor Real 0.75...1.50 - -
79.61 Fault reset time Real 1.0...1200.0 s 1 = 1
79.71 Motor factor Real 0.1...6.0 - -
80 Flow calculation
80.01 Calculated flow Real 0.00...200000.00 m
3
/h 100 = 1
80.03 Total flow Real 0.00...21474836.00 m
3
100 = 1
80.06 Today’s flow Real 0.00...21474836.00 m
3
100 = 1
80.07 Sensored flow Real 0...2147483648 - 100 = 1
80.13 Flow function List --1 = 1
80.14 Flow calc gain Real 0.50...2.00 - 100 = 1
80.21 Pump nominal speed Real 0...30000 rpm 100 = 1
80.26 Calc low speed Real 0.00...32767.00 Hz 100 = 1
80.29 Reset flow List 0, 1 - 1 = 1
80.50 PQ curve P1 Real 0.00...32767.00 kW 100 = 1
80.51 PQ curve P2 Real 0.00...32767.00 kW 100 = 1
80.52 PQ curve P3 Real 0.00...32767.00 kW 100 = 1
80.53 PQ curve P4 Real 0.00...32767.00 kW 100 = 1
80.54 PQ curve P5 Real 0.00...32767.00 kW 100 = 1
80.60 Q value Q1 Real 0.00...200000.00 m
3
/h 100 = 1
80.61 Q value Q2 Real 0.00...200000.00 m
3
/h 100 = 1
80.62 Q value Q3 Real 0.00...200000.00 m
3
/h 100 = 1
80.63 Q value Q4 Real 0.00...200000.00 m
3
/h 100 = 1
80.64 Q value Q5 Real 0.00...200000.00 m
3
/h 100 = 1
82 Pump protections
82.02 Dry run source List 0...8 - 1 = 1
82.46 Dry run current limit Real 0.00...3000.00 A 100 = 1
No. Name Type Range Unit FbEq32
