72 Parameters
05.02 Run-time counter Motor run-time counter. The counter runs when the inverter
modulates.
0
0…65535 d Motor run-time counter. 1 = 1 d
05.03 Pump run hours Shows the pump running time in hours. The pump run hours
is based on the value in parameter 05.02 Run-time counter
and is calculated as, 24 * 05.02 value + fractional part of a
day.
-
0.0…
429496729.5 h
Hours. 1 = 1 h
05.04 Fan on-time
counter
Shows running time of the drive cooling fan. Can be reset
from the control panel by keeping Reset down for over 3
seconds.
0
0…65535 d Cooling fan run-time counter. 1 = 1 d
05.10 Control board
temperature
Shows measured temperature of the control board 0
-100… 300 °C Control board temperature in degrees Celsius or Fahrenheit. 1 = unit
05.11 Inverter
temperature
Shows estimated drive temperature in percent of fault limit.
The fault limit varies according to the type of the drive.
0.0% = 0 °C (32 °F)
100.0% = Fault limit
0
-40.0…160.0% Drive temperature in percent. 1 = 1%
05.20 Diagnostic word 1 Diagnostic word 1. For possible causes and remedies, see
chapter Fault tracing.
0b0000
0b0000...0b1111 Diagnostic word 1. 1 = 1
05.21 Diagnostic word 2 Diagnostic word 2. For possible causes and remedies, see
chapter Fault tracing.
0b0000
0b0000...0b1111 Diagnostic word 2. 1 = 1
No. Name/Value Description Def/FbEq16
Bit Name Value
0 Any warning or fault Yes = Drive has generated a warning or tripped on a fault.
1 Any warning Yes = Drive has generated a warning.
2 Any fault Yes = Drive has tripped on a fault.
3 Reserved
4 Overcurrent flt Yes = Drive has tripped on fault 2310 Overcurrent.
5 Reserved
6 DC overvoltage Yes = Drive has tripped on fault 3210 DC link overvoltage.
7 DC undervoltage Yes = Drive has tripped on fault 3220 DC link undervoltage.
8 Reserved
9 Device overtemp flt Yes = Drive has tripped on fault 4310 Excess temperature.
10...15 Reserved
Bit Name Value
0...9 Reserved
10 Motor overtemperature fault Yes = Drive has tripped on fault 4981 External
temperature 1 or4982 External temperature 2
11...15 Reserved
