66 ACS 400 User’s Manual
0125 ACTUAL VALUE 2 0 - 100 % 0.1 % -
0126
CONTROL DEV -100 - 100 % 0.1 % -
0127
PID ACT VALUE -100 - 100 % 0.1 % -
0128 LAST FAULT 0 - 26 1 -
0129
PREVIOUS FAULT 0 - 26 1 -
0130
OLDEST FAULT 0 - 26 1 -
0131
SER LINK DATA 10 - 255 1 -
0132
SER LINK DATA 20 - 255 1 -
0133
SER LINK DATA 30 - 255 1 -
0134
PROCESS VAR 1- - -
0135
PROCESS VAR 2- - -
0136
RUN TIME 0.00 - 99.99 kh 0.01 kh -
0137 MWh
COUNTER 0 - 9999 MWh 1 MWh -
Group 10
COMMAND INPUTS
1001
EXT1 COMMANDS 0 - 10 1 * áá
1002 EXT2 COMMANDS 0 - 10 1 * áá
1003 DIRECTION 1 - 3 1 * áá
Group 11
REFERENCE SELECT
1101
KEYPAD REF SEL 1 - 2 1 1 (REF1 (Hz))
1102
EXT1/EXT2 SEL 1 - 8 1 * áá
1103 EXT REF1 SELECT 0 - 10 1 * áá
1104 EXT REF1 MIN 0 - 250 Hz 1 Hz 0 Hz
1105 EXT REF1 MAX 0 - 250 Hz 1 Hz * á
1106 EXT REF2 SELECT 0 - 10 1 * áá
1107 EXT REF2 MIN 0 - 100 % 1 % 0 %
1108
EXT REF2 MAX 0 - 500 % 1 % 100 %
Group 12
CONSTANT SPEEDS
1201
CONST SPEED SEL 0 - 10 1 * áá
1202 CONST SPEED 1 0 - 250 Hz 0.1 Hz 5 Hz
1203 CONST SPEED 2 0 - 250 Hz 0.1 Hz 10 Hz
1204 CONST SPEED 3 0 - 250 Hz 0.1 Hz 15 Hz
1205
CONST SPEED 4 0 - 250 Hz 0.1 Hz 20 Hz
1206
CONST SPEED 5 0 - 250 Hz 0.1 Hz 25 Hz
1207
CONST SPEED 6 0 - 250 Hz 0.1 Hz 40 Hz
1208
CONST SPEED 7 0 - 250 Hz 0.1 Hz 50 Hz
Group 13
ANALOG INPUTS
1301 MINIMUM AI1 0 - 100 % 1 % 0 %
1302
MAXIMUM AI1 0 - 100 % 1 % 100 %
1303
FILTER AI1 0 - 10 s 0.1 s 0.1 s
1304
MINIMUM AI2 0 - 100 % 1 % 0 %
Code Name Range Resolution Default User S M
