Maintenance
103
Capacitors
The drive intermediate circuit employs several electrolytic capacitors. The lifespan
depends on drive loading and ambient temperature. Capacitor life can be prolonged
by lowering the ambient temperature.
It is not possible to predict a capacitor failure. Capacitor failure is usually followed by
a mains fuse failure or a fault trip. Contact ABB if capacitor failure is suspected.
Replacements for frame size R4 and up are available from ABB. Do not use other
than ABB specified spare parts.
Reforming
Reform (re-age) spare part capacitors once a year according to Converter modules
with electrolytic DC capacitors in the DC link, Capacitor reforming instructions
(3BFE64059629 [English]).
LEDs
This table describes LEDs of the drive.
* The LEDs are not visible in frame sizes R2 to R6.
Where LED When the LED is lit
RMIO board * Red Drive in fault state
Green The power supply on the board is OK.
Control panel mounting platform
(with type code selection +0J400
only)
Red Drive in fault state
Green The main +24 V DC power supply for the control panel and the
RMIO board is OK.
