Type code
The type code contains information on the specifications and configuration of the
drive. The first digits from left express the basic configuration (for example,
ACS800-01-0006-5). The optional selections are given thereafter, separated by +
signs (for example, +E202). The main selections are described below. Not all
selections are available for all types. For more information, refer to ACS800
Ordering Information (EN code: 3AFY64556568, available on request).
Selection Alternatives
Product series ACS800 product series
Type 01 Wall mounted. When no options are selected: IP21, control panel CDP 312R,
no EMC filter, Standard Control Program, cable connection box (cabling from
below), brake chopper in frame sizes R2 and R3 (230/400/500 V units) and in
frame size R4 (690 V units), boards without coating, one set of English
manuals.
U1 Wall mounted (USA). When no options are selected: UL type 1, control panel
CDP 312R, no EMC filter, US version of the Standard Control Program (three-
wire start/stop as default setting), US gland/conduit box, brake chopper in
frame sizes R2 and R3 (230/400/500 V units) and in frame size R4 (690 V
units), boards without coating, one set of English manuals.
Size Refer to Technical data: IEC data or NEMA data.
Voltage range
(nominal rating in bold)
2 208/220/230/240 V AC
3 380/400/415 V AC
5 380/400/415/440/460/480/500 V AC
7 525/575/600/690 V AC
Option codes (+ codes)
Degree of protection B056 IP55 / UL type 12
Construction C131 Vibration dampers
C132 Marine type approved unit (coated boards included, +C131 required for frame
sizes R4 to R6 in wall installations, +C131 not required in cabinet installations)
Resistor braking D150 Brake chopper
Filter E200 EMC/RFI filter for second environment TN (grounded) system, drive category
C3 (frame sizes R2…R5)
E202 EMC/RFI filter for first environment TN (grounded) system, drive category C2
E210 EMC/RFI filter for second environment TN/IT (grounded/ungrounded) system,
drive category C3 (frame size R6 only)
Cabling H358 US/UK gland/conduit box
Control panel 0J400 No control panel
Fieldbus K... Refer to ACS800 Ordering Information (EN code: 3AFY64556568).
I/O L...
Control program N...
Manual language R...
Safety features Q950 Prevention of unexpected start-up: AGPS board and 3 m connection cable
(not to be used with option +Q967)
Q967 Safe torque off (STO) function without safety relay: ASTO board and 3 m
connection cable (not to be used with option +Q950)
Specialities P901 Coated boards
P904 Extended warranty
