ABB ACS800-01-0070-3 User Manual

Technical data
117
Cable entries
Brake resistor, mains and motor cable terminal sizes (per phase), accepted cable
diameters and tightening torques are given below
.
* 16 mm
2
rigid solid cable, 10 mm
2
flexible stranded cable
** with cable lugs 16...70 mm
2
, tightening torque 20...40 Nm. These smaller cable lugs are not included
in the delivery. See page 67.
†
In -0205-3 and -0255-5 units, the maximum cable diameter is 69 mm (IP21 units) or 40...60 mm (IP55
units).
Dimensions, weights and noise
H1: height with cable connection box
H2: height without cable connection box.
* In -0205-3 and -0255-5 units, H1 is 977 mm and weight is 70 kg.
Package dimensions and weights
Frame
size
U1, V1, W1, U2, V2, W2, R+, R- Earthing PE
Wire size Max. cable Ø
IP21
Cable Ø
IP55
Tightening
torque
Wire size Tightening
torque
mm
2
mm mm Nm mm
2
Nm
R2 up to 16* 21 14...20 1.2...1.5 up to 10 1.5
R3 up to 16* 21 14...20 1.2...1.5 up to 10 1.5
R4 up to 25 29 23...35 2…4 up to 16 3.0
R5 6...70 35 23...35 15 6...70 15
R6 95...240 **
†
53
†
30...45
†
20...40 95 8
Frame
size
IP21 IP55 Noise
H1 H2 Width Depth Weight Height Width Depth Weight
mm mm mm mm kg mm mm mm kg dB
R2 405 370 165 226 9 528 263 241 16 62
R3 471 420 173 265 14 528 263 273 18 62
R4 607 490 240 274 26 774 377 278 33 62
R5 739 602 265 286 34 775 377 308 51 65
R6 880* 700 300 399 67* 923 420 420 77 65
Frame size IP21 IP55
H1 Width Depth Weight Height Width Depth Weight
mm mm mm kg mm mm mm kg
R2 400 470 270 2 370 620 390 5
R3 430 500 270 2 370 620 390 5
R4 520 560 340 2 410 860 460 5
R5 540 670 350 2 410 860 460 5
R2-R5
with option +Q950
or +Q967
580 930 560 17 580 930 560 17
R6 549 1085 400 15 577 1250 565 20
