ABB ACS800-01-0070-3 User Manual

Technical data
124
Cooling
Method Internal fan, flow direction from bottom to top.
Free space around the unit See chapter Mechanical installation.
Degree of protection
IP21 (UL type 1) and IP55 (UL type 12). Without the connection box and front cover, the
unit must be protected against contact according to IP2x [see chapter Electrical
installation: Cabinet installation (IP21, UL type 1)].
AGPS-11C (option +Q950)
Nominal input voltage 115...230 VAC ±10%
Nominal input current 0.1 A (230 V) / 0.2 A (115 V)
Nominal frequency 50/60 Hz
Max. external fuse 16 A
X1 terminal sizes 3 x 2.5 mm
2
Output voltage 15 VDC ±0.5 V
Nominal output current 0.4 A
X2 terminal block type JST B4P-VH
Degree of protection IP20
Ambient temperature 0...50 °C (32...122 °F)
Relative humidity Max. 90%, no condensation allowed
Dimensions (with enclosure) 167 x 128 x 52 mm (height x weight x depth)
Weight (with enclosure) 0.75 kg (1.65 lb)
Approvals C-UL, US listed
ASTO-11C (option +Q967)
Supply voltage range +24 V DC +/- 10%
Current consumption 40 mA (20mA per channel)
Supply cable A single-shielded twisted pair
Maximum cable length 300 m
Conductor min. cross
section
0.5 mm
2
, 20 AWG
X1 terminal sizes 4 x 2.5 mm
2
Nominal output current 0.4 A
X2 terminal block type JST B4P-VH
Degree of protection IP20
Ambient temperature 0...50 °C (32...122 °F)
Relative humidity Max. 90%, no condensation allowed
Altitude in operation 0…2000 m (6562 ft)
Dimensions (with enclosure) 167 x 128 x 52 mm (height x weight x depth)
Weight (with enclosure) 0.75 kg (1.65 lb)
