DCS550 DC Drives
Technical data
Mains supply volt. 230...525 V,
+/–10 %, 3~
Frequency 50...60 Hz, +/–5
Hz
Electronics supply 115...230 V,
–15 % / +10 %, 1~
DC Output current 20...1000 A
Overload capability 200 %
Ambient conditions
Ambient temperat. 0° ... +40° C
40° ... 50°C with
reduction
Storage temperat. –40° ... +55° C
Transport temper. –40° ... +70° C
Relative humidity 5 ... 95 %, not
condensing
(max. 50 % betw.
0°...5° C)
Pollution degree Class 2
Protection class IP 00
Altitude < 1,000 m height
above sea level:
nominal Current
> 1,000 m height
above sea level:
with reduction
I/O
Digital inputs: 8 standard, up to
14 optional
Digital outputs: 5 standard, up
to 9 optional
Analog inputs: 4 standard +/–
10 V; 0/2…10 V, up to 8 optional
+/ 20 mA; 0/4…20 mA
Analog outputs: 3 standard (1x
I
act
) +/-10 V; 0/2…10 V, up to 7
optional –20 mA; 0/4…20 mA
PC-Tools
DriveWindow Light: free of
charge with every converter,
Standard RS232 PC-connection
Communication
Serial communication
• Ethernet • Profibus
• CANopen • DeviceNet
• ControlNet • EtherCat
• Modbus • ProfiNet
Industrial IT
©
enabled
Protections
Speed feedback monitoring •
Temperature • Overload • Over
speed • Motor stalled • Motor
over current • Motor over voltage
• Field over current • Minimum
field current • Zero speed •
Armature current ripple • Mains
over- and under voltage
Approvals
(in preparation 12/2011)
Adaptive Programming
pre-defined drive-specific function
blocks, e.g.
• Free process controller (PI-
Controller)
• I/O- and digital Operations
With control panel or PC-Tool, no
need for additional hardware
Speed Feedback
EMF
Analog tacho
Encoder
Unit
size
2-Q
rated Current
DCS550-S01
4-Q
rated Current
DCS550-S02
Supply voltage
[V
AC
]
max. field
current
internal
Dimensions
I
DC
[A] I
DC
[A] 230 400 525 [A
DC
] h x w x d [mm] h x w x d [inch]
F1 20 25 12 370 x 270 x 208 14.56 x 10.65 x 8.20
45 50
65 75
90 100
F2 135 150 18 370 x 270 x 264 14.56 x 10.65 x 10.40
180 200
225 250
270 300
F3 315 350 25 459 x 270 x 310 18.07 x 10,65 x 12,25
405 450
470 520
F4 610 680 35 644 x 270 x 345 25.35 x 10.65 x 13.60
740 820
900 1000
Current ratings, dimensions
