80 3ADW000395R0100 DCS550 Quick guide edisf a80 3ADW000395R0100 DCS550 Quick guide edisf a
Fault list — Fehlerliste — Errore di lista — Lista de errores — Liste des erreurs
LED
Fault Word
Text on DCS550 Panel,
DriveWindow Light and
DriveWindow
Definition
EN
Text in DCS550 Panel,
DriveWindow Light und
DriveWindow
Beschreibung
D
Testo DCS550 Pannello,
DriveWindow Light e
DriveWindow
Descrizione
IT
Texto en el DCS550 Panel,
DriveWindow Light y
DriveWindow
Definición
SP
Texte dans la DCS550
Microconsole,
DriveWindow Light et
DriveWindow
Description
FR
F501 9.01 Bit 0
AuxUnderVolt Auxiliary undervoltage, terminal X99 on SDCS-PIN-F and SDCS- POW-F
AuxUnderVolt Hilfs-Unterspannung, Klemme X99 auf SDCS-PIN-F und SDCS-POW-F
AuxUnderVolt Guasto tensione ausiliaria
AuxUnderVolt Fallo de tensión auxiliar (Subtensión auxil.)
AuxUnderVolt Défaut tension auxiliaire
F502 9.01 Bit 1 ArmOverCur
Armature overcurrent, ArmOvrCurLev (30.09)
ArmOverCur Überstrom Anker, ArmOvrCurLev (30.09)
ArmOverCur Sovracorrente, ArmOvrCurLev (30.09)
ArmOverCur Sobrecorriente (Sobrecorriente), ArmOvrCurLev (30.09)
ArmOverCur Surintensité, ArmOvrCurLev (30.09)
F503 9.01 Bit 2 ArmOverVolt
Armature overvoltage (DC), ArmOvrVoltLev (30.08)
ArmOverVolt Überspannung Gleichstromkreis (DC), ArmOvrVoltLev (30.08)
ArmOverVolt Sovratensione d’indotto (circuito in c.c.), ArmOvrVoltLev (30.08)
ArmOverVolt Sobretensión de inducido (circuito de C.C.), ArmOvrVoltLev (30.08)
ArmOverVolt Surtension d’induit (circuit c.c.), ArmOvrVoltLev (30.08)
F504 9.01 Bit 3 ConvOverTemp
Converter overtemperature, MaxBridgeTemp (4.17)
ConvOverTemp Übertemperatur Stromrichter, MaxBridgeTemp (4.17)
ConvOverTemp Sovratemperatura sezione di potenza, MaxBridgeTemp (4.17)
ConvOverTemp Sobretemperatura en la sección de potencia, MaxBridgeTemp (4.17)
ConvOverTemp Echauffement anormal du pont de puissance, MaxBridgeTemp (4.17)
F506 9.01 Bit 5 M1OverTemp
Motor measured overtemperature, M1FaultLimTemp (31.07)
M1OverTemp Motor 1 gemessene Übertemperatur, M1FaultLimTemp (31.07)
M1OverTemp Motore 1 sovratemperatura, M1FaultLimTemp (31.07)
M1OverTemp Motor 1 sobretemperatura, M1FaultLimTemp (31.07)
M1OverTemp Moteur 1 echauffement anormal, M1FaultLimTemp (31.07)
F507 9.01 Bit 6 M1OverLoad
Motor calculated overload, M1FaultLimLoad (31.04)
M1OverLoad Motor 1 berechnete Überlast, M1FaultLimLoad (31.04)
M1OverLoad Motore 1 sovraccarico, M1FaultLimLoad (31.04)
M1OverLoad Motor 1 sobrecarga, M1FaultLimLoad (31.04)
M1OverLoad Moteur 1 surcharge, M1FaultLimLoad (31.04)
F508 9.01 Bit 7 I/OBoardLoss
I/O board not found or faulty, see groups 94 and 98
I/OBoardLoss E/A-Karte nicht gefunden oder fehlerhaft, s. Gruppe 94 und 98
I/OBoardLoss I/OBoardLoss
Tarjetas E/S no encontradas o faltan, comprobar parámetros gr. 94 y 98.
I/OBoardLoss
F512 9.01 Bit 11 MainsLowVolt
Mains low (under-) voltage (AC), UnetMin1 (30.22)
MainsLowVolt Netz-Unterspannung (AC), UnetMin1 (30.22)
MainsLowVolt Minima tensione di alimentazione di rete (c.a.), UnetMin1 (30.22)
MainsLowVolt Tensión Baja de red (C.A.), UnetMin1 (30.22)
MainsLowVolt Sous-tension réseau (c.a.) , UnetMin1 (30.22)
F513 9.01 Bit 12 MainsOvrVolt
Mains overvoltage (AC), > 1.3 * NomMainsVolt (99.10)
MainsOvrVolt Netz-Überspannung (AC), > 1.3 * NomMainsVolt (99.10)
MainsOvrVolt Sovratensione alimentazione di rete (c.a.), > 1.3 * NomMainsVolt (99.10)
MainsOvrVolt Sobretensión de red (C.A.), > 1.3 * NomMainsVolt (99.10)
MainsOvrVolt Surtension réseau (c.a.), > 1.3 * NomMainsVolt (99.10)
F514 9.01 Bit 13 MainsNotSync
Mains not in synchronism (AC), DevLimPLL (97.13)
MainsNotSync Netz nicht synchronisiert (AC), DevLimPLL (97.13)
MainsNotSync Guasto di sincronizzazione (c.a.), DevLimPLL (97.13)
MainsNotSync Fallo de sincronización (C.A.), DevLimPLL (97.13)
MainsNotSync Défaut de synchronisation (c.a.), DevLimPLL (97.13)
F515 9.01 Bit 14 M1FexOverCur
Field exciter overcurrent, M1FldOvrCurLev (30.13)
M1FexOverCur Motor 1 Überstrom Feldversorgung, M1FldOvrCurLev (30.13)
M1FexOverCur Motore 1 Sovracorrente ECCITATRICE DI CAMPO, M1FldOvrCurLev (30.13)
M1FexOverCur Motor 1 Sobrecorriente de la EXCITACIÓN, M1FldOvrCurLev (30.13)
M1FexOverCur Moteur 1 Surintensité EXCITATION, M1FldOvrCurLev (30.13)
F517 9.02 Bit 0 ArmCurRipple
Armature current ripple, CurRippleSel (30.18)
ArmCurRipple Welligkeit Ankerstrom, CurRippleSel (30.18)
ArmCurRipple Ondulazione della corrente d’indotto, CurRippleSel (30.18)
ArmCurRipple Rizado de la corriente (corriente) del inducido, CurRippleSel (30.18)
ArmCurRipple Ondulation courant d’induit, CurRippleSel (30.18)
