Tension Electronics PFEA113, User Manual
Section A.4 Technical Data
3BSE029382R0101 Rev C A-7
A.4 Technical Data
Table A-2. Data for Supply Voltage
Data Comments
Supply voltage
IP 20-unit (unsealed)
IP 65-unit (NEMA 4)
24 V DC
24 V DC
85 - 264 V AC
18 - 36 V DC
18 - 36 V DC
100 V -10% to 240 V +10%
Mains frequency 45 - 65 Hz 100-240 V AC, 0.3 - 0.135 A
Power
consumption
15 W (24 V) Digital outputs not included
Fuse
IP 20-unit (unsealed)
IP 65-unit (NEMA 4)
Automatic reset
Slow blow, 2 A, 250 V
Table A-3. Data for Load Cell Excitation
Data Comments
Current 0.5 A rms, 330 Hz Regulated
Max. load Four load cells + max. 10
cable resistance (1 F cable
capacitance).
Load cells of type:
PFCL 301E, PFTL 301E,
PFRL 101, PFTL 101,
PFCL 201 and PFTL 201.
Table A-4. Data for Load Cell Inputs
Data Comments
Number of inputs 4
Input impedance 10 k
