ABB PFEA 113 User Manual

Tension Electronics PFEA113, User Manual
Section F.13 Dimension Drawing, 3BSE006699D0003, Rev. F
3BSE029382R0101 Rev C F-17
F.13 Dimension Drawing, 3BSE006699D0003, Rev. F
REV DESCRIPTION DATE DEPT./INIT.
- New document 1994-11-11 SEISY/AGK/IL
A Dimension-, shape- and positional tolerances added. 1999-02-17 SEAPR/AGK/RL B 125 (+0, -0.2) was 125±0.2; Flatness tol. 0.02 was 0.1; 1995-05-03 SEAPR/AGK/ML
C New product name, new tolerances. 2000-12-18 SEAPR/AGV/AB D Dimension 450±0.1 was 450±0.2. 125+0/-0.2 was 125±0.1 2005-01-28 ATPA/FM/GF/LEN
E Dimension 124.6±0.05 was 125+0/-0.2 2005-09-26 ATPA/FM/GF/LEN
F
View A added. Views in sheet 2 were in sheet 1. Holes Ø8.0 added. Hole callout M16 adjusted. Hidden edges removed. Geometric tolerances added. Dimensions adjusted.
2011-12-27 PA/FM/GF/ML

 

 

 
 
 
 

 

 
 

 

 
C

 
 
ABB AB
2012-01-13
Cont.sh./ No of sh. SheetLang. Rev.
Project or order number : Modify date :
Document number
Appr. Prep. Resp.dept
Product type designation : Product information : Product family :
2012-01-04 14:13:56
PFC100
661130 Bansp.mätare VPBT/HPBT
ABB AB

 
Håkan F Wintzell

 
2012-01-11Magnus X Lindström

 
1 1F
en
Lastcell PFCL 201C Load cell PFCL 201C Dimension drawing
3BSE006699D0003
PA PA PA
PA/FM/GF FM/GF FM/GF
Document status:
Approved
Customer reference :
/ / /
= Force component (not measured).
F
v
= Measured component.
R
F
F
v
F
R
(
F
R
)
450
124,6 ±0,05
0,1 CZ
0,1 CZ
0,2 A
A
110
18 X 90°
4 x M16
25
9 X 90°
2 x Ø8.0 H8
10
70 ±0,4
220 ±0,4
(holes M16)
220 ±0,2
(holes
8.0)
20
9 X 90°
2 x Ø8.0 H8
10
18 X 90°
4 x M16
25
70 ±0,4
410 ±0,4
(holes M16)
410 ±0,2
(holes
8.0)
20
