Tension Electronics PFEA113, User Manual
Chapter 3 Commissioning
3-12 3BSE029382R0101 Rev C
3.11 Performing a Complete Setup
3.11.1 Overview
The complete setup is built up by a number of main and sub menus. The table below shows the
main menus in order of appearance when stepping through the complete setup. The table also
gives an overview of the selections and parameter settings you can do below in each main menu.
The complete setup sequence is described in Section 3.12.
Main menus Selections and parameter settings
See
details
in
section
...
Set language
Set unit/web width
Set decimals
3.12.1
Load cell combination:
- One roll
- Two rolls or
- Segmented roll
Gain scheduling: Yes/No
3.12.2
Set object type:
- Standard roll (Roll 1, load cells A and B or
Roll 2, load cells C and D)
- Single side measurement (Roll 1, load cell A or B
Roll 2, load cell C or D)
- Segmented roll
3.12.3
Set nominal load 3.12.4
Zero set load cells 3.12.5
Hang weight (actual force) or
Enter wrap gain (calculated value)
3.12.6
