Tension Electronics PFEA113, User Manual
Chapter 4 Operation
4-6 3BSE029382R0101 Rev C
4.7.1 Web Tension
4.7.1.1 Standard Roll (two load cells), One or Two Rolls
The following menus are available when a standard roll (two load cells) is connected to the
tension electronics:
• One roll
–WebTension
Shows the total web tension measured by load cell A and load cell B
– Tension A
Shows the part of web tension measured by load cell A
– Tension B
Shows the part of web tension measured by load cell B
– TensionDiff A-B
Shows the difference between Tension A and Tension B
• Two rolls
Tension menus, Roll 1:
– TensionRoll 1
Shows the total web tension measured by load cell A and load cell B
– Tension A
Shows the part of web tension measured by load cell A
– Tension B
Shows the part of web tension measured by load cell B
– TensionDiff A-B
Shows the difference between Tension A and Tension B
Tension menus, Roll 2:
– TensionRoll 2
Shows the total web tension measured by load cell C and load cell D
– Tension C
Shows the part of web tension measured by load cell C
– Tension D
Shows the part of web tension measured by load cell D
– TensionDiff C-D
Shows the difference between Tension C and Tension D
