ABB PFEA 113 User Manual

Tension Electronics PFEA113, User Manual
Chapter 3 Commissioning
3-34 3BSE029382R0101 Rev C
3.12.9 Setting Analog Inputs (AI1 and AI2)
There are two analog inputs.
The input signal range is 0 to 10 V.
Analog inputs are used to connect two or three PFEA113 together.
To scale the analog inputs the following must be set:
• High Tension (N, kN, kg, lbs, N/m, kN/m, kg/m, pli)
• High Input V
Figure 3-19. Menus for Analog inputs
See also Section 3.12.3.3 for segmented roll application.
3.12.10 Setting the Digital Input
The digital input is used for Zero Set or Gain Scheduling. The input is set to Off, if not used.
Use up and down keys to select:
• Off
• ZeroSet or
• GainScheduling
AI 1
HighInput
[XX.XX] V
HighInput
XX.XX V
HighTension
[XXXXXX.X] N
HighTension
XXXXXX.X N
To DI
AI 2
HighInput
[XX.XX] V
HighInput
XX.XX V
HighTension
[XXXXXX.X] N
HighTension
XXXXXX.X N
FastSetUp
WebTension
Presentation-
Menu
SetNominal-
Load
ServiceMenu
ZeroSet
SetWrapGain
> 5 s
AO 1 - AO 6
Miscellaneous
Menu
System-
Definition
ObjectType
DO 1 - DO 4
AI 1 - AI 2
DI
To MiscellaneousMenu
DI
Define DI
[XX]
Define DI
XX
From AI 2
